Chipboard screw, full thread, clear zinc, pozidriv
Anklicken des Bildes zum Zoomen
Beschreibung
Chipboard screw, full thread, clear zinc, pozidriv
- Harmonized standard EN 14592:2008+A1:2012
Spezifikationen
Identifizierung
- Article number
- 32008035025
- GTIN
- 8715274238333
Technische Spezifikationen
- Wire material
- Carbon steel standard tensile
Spezifikationen für Befestiger
- Finish
- Clear zinc
- Application environment
- Indoor
- Point type
- Sharp
- Screw head type
- Countersunk
- Screw recess
- Pozidrive 2
- Screw thread type
- Full thread
- Screw length
- 25.0 mm
- Screw diameter
- 3.5 mm
CE-Spezifikationen
- Characteristic head pull through parameter
- 14.0 N/mm²
- CE fastener type
- Chipboard screw
- DOP No
- 32008035025
- Material notification on CE label
- Carbon Steel
- Protection level in micron
- 3
- Threaded/profiled length
- 25.0 mm
- Characteristic yield moment
- 1600.0 Nmm
- Torsional ratio
- ≥1.5
- Characteristic torsional strength
- 2.1 Nm
- Characteristic tensile capacity
- 3000.0 N
- Harmonized standard
- EN 14592:2008+A1:2012
- Characteristic withdrawal parameter
- 9.5 N/mm²
Nicht-technische Spezifikationen
- Package quantity
- 200
Logistische Spezifikationen
- Net weight
- 0.24 kg
