Stahl auf Stahlbefestigung Schraube PH2 Klarer Zink 4,8x19mm

Anklicken des Bildes zum Zoomen

Beschreibung

Schraube Stahl auf Stahl, verzinkt

Mehr anzeigen Weniger anzeigen

Anwendungen

Stahl auf Stahl

Mehr anzeigen Weniger anzeigen

Harmonisierte Norm EN 14566:2008+A1:2009

Informationen anfordern

Spezifikationen

Identifizierung

Artikelnummer: 48IP19MC
GTIN: 8715274028149

Technische Spezifikationen

Legierungstyp: Kunststoffcolliert
Drahtmaterial: Kohlenstoffstahl Standard Zugfestigkeit
Umdrehungen pro Minute: 2300, 2500, 3000, 3300 RPM

Spezifikationen für Befestiger

Oberfläche: Klarer Zink
Anwendung: Innenbereich
Spitzenart: Typ 17 Schneidspitze
Spitzenwinkel: 110 °
Schraubenkopf-Typ: Flach
Schraubenantrieb: Philips 2
Schraubengewinde: Bohrspitze
Menge Befestiger je Streifen / Coil: 50 - 50
Schraubenlänge: 19.0 mm
Schraubendurchmesser: 4.8 mm

CE-Spezifikationen

DOP No: 48IP19MC
Nutzungsklasse: 1
Innengewindedurchmesser: 3.8 mm
Gewindelänge: 13.9 mm
Harmonisierte Norm: EN 14566:2008+A1:2009

Nicht-technische Spezifikationen

Anzahl der Packstücke: 1000

Logistische Spezifikationen

Nettogewicht: 2.4 kg

Verbundene Werkzeuge

Downloads

48IP19MC_de_CommercialProductSheet_1.5_1752233782274 PDF 1 Mb
48IP19MC_de_DeclarationOfPerformanceDoP_1.1eu_1750109882123 PDF 59 Kb
